●System  Specification

Stabilization:≤ 50 µrad(1σ) (2 ° / 1Hz, 1° / 2Hz swing

Weight: ≤ 2kg

Size:≤Φ 150mm× 205mm

Environmental protection:IP64

Operating Temperature:-20℃~60℃

Rotation Limits:

Azimuth axis: n× 360 ° continuous rotation

Pitch Axis: -110 °~+ 10 ° (0 ° horizontal, positive upward)

Slew Rate: 50 ° / s

Power:20W typical/ 50W peak

Voltage:20 V ~ 28 V

Video out: Digital H.264 encoded video

Control interface：RS422

●Onboard Image Processor Specification

Object Tracking：   Yes

Scene Steering:   yes

Software Stabilization:  Yes

Software Roll Correction： Yes

Video Output:     HD-SDI,1080p,30Hz

H264.encoding:    Yes

Geo-Location Feature:   Yes

Moving Map Software:   Yes

●Laser Rangefinder Specification

Ranging accuracy: ± 1m

Laser distance distance: 50 ~ 3,000 m

EO Sensor Specification

Field of View： 63.7 º~1.1º

Resolution:1920x1080

Optical Zoom：30x

Digital Zoom:  2x

●IR Sensor Specification

Type: LWIR uncooled

Field of View:14.6.× 11.7

Resolution:640× 512

Frame Rate:30fps

The focal length :42mm/F1.0

Sensitivity:60mK
